75-160mm HDPE/PP Three Layers/Two Layers Water Pipe Extrusion Production Line

Share to:

75-160mm HDPE Multi Layer Water Pipe Extrusion Line

5 0 Reviews

75-160mm HDPE multi layer water pipe extrusion line for two-layer or three-layer PE/PP water pipe projects. This older page supports multi-layer long-tail searches and links to the main 75-250mm PE pipe line.

Availability:

Quantity:



Inquire Add to Basket

Product Description

75-160mm HDPE Multi Layer Water Pipe Extrusion Line

Winsoar 75-160mm HDPE Multi Layer Water Pipe Extrusion Line is maintained as a PE pipe extrusion support page for 75-160mm multi-layer HDPE water pipe inquiries. It is not the main PE category page; buyers should use the linked core PE pages below to confirm the final diameter range and configuration.

This page is useful for buyers comparing two-layer or three-layer PE pipe structures in the 75-160mm range. The 75-250mm PE pipe production line remains the main product page for medium-diameter PE pipe projects.

Configuration Notes for This Application

A multi-layer PE pipe line can use main extruder plus co-extruder, multi-layer die head, vacuum calibration, cooling tank, haul-off, cutter and stacker. Layer ratio, material grade, die design and melt stability should be confirmed carefully.

For standard medium PE pipe projects, compare the linked 75-250mm PE core page first. For larger pressure pipe, review 200-400mm PE as the next range.

Quotation Checklist

Please prepare pipe diameter range, SDR or wall thickness, raw material, application, output target, cutting or coiling requirement, voltage and available factory space. These details help Winsoar recommend the extruder, die head, vacuum calibration tank, cooling tank, haul-off, cutter and downstream equipment correctly.

Related PE Pipe Extrusion Resources

For the main product range, visit the PE Pipe Production Line category.

Useful guides: PE pipe line machine configuration, PE pipe production process, PE pipe line cost guide and HDPE pipe extrusion line selection guide. Video references: 75-250mm PE video solution, 200-400mm PE video solution.

Features

1) It is mainly used in producing pipe material whose raw material is mainly HDPE granules. It is also suitable for producing pipe materials of PP, PE resin etc.

2) It has been widely applied to the transportation of housing cold-hot water and liquid gas.

3) The PPR/PE pipe production line is a new type of environmentally friendly product of the National Ministry of Construction.

4) We introduce the latest overseas technology, which fully displays our technical superiority.

5) This production line has higher output, good plasticized performance, and higher pipe pressure resistance.

Key Components

SINGLE SCREW EXTRUDER

The single screw extruder is simple in design and inexpensive, so it is widely used. It is suitable for extrusion production of PE, PPR, PERT plastic pipes, sheets and profiles.
MARK LINE CO-EXTRUDER

The extruder is especially widely used on pipe production line to co-extrude pipe mark line. It is specially designed with lower power consumption and takes smaller space.
EXTRUSION DIE

After compaction, melting, mixing and homogenization of PP the subsequent material is pushed to the die by the screw. The extrusion die is the most important part of tube forming.
VACUUM CALIBRATION TANK

Used for shaping and cooling of pipes, it is equipped with a vacuum system, water circulation system, as well as front and rear moving device and left and right, height adjustment manual device, stainless steel box, circulating water spray cooling.
SPRAY COOLING TANK

The cooling water is atomized and sprayed from the special nozzle after being pressed by the water pump, so that the product can be cool to 360 degrees in all directions.
TRACTOR

It is used to continuously and automatically lead out the cooled and hardened pipes from the machine head, and the speed is controlled by frequency conversion.
CUTTING MACHINE

After being controlled by encoder according to the required length, automatic cutting is carried out, the stacker is turned over with a delay, pipes are cutted smoothly without scraps and dust.
AUTOMATIC WINDING MACHINE

This machine is equipped with two reels alternately to ensure the continuity of production. It is suitable for plastic rewinding and packaging, automatic arranging,automatic rewinding, and easy operation.
TURNOVER RACK (OPTIONAL ON REQUEST)

Accept finished products and automatically turn over.

Main Technical Parameter

33D Series Classical Production Line：

Production Line	Diameter Range（mm）	Extruder Type	Max. Capacity （kg/h）	Max. Haul Off Speed（m/min）	Extrusion Power（kw）
WS-63 I	Ф 20-63	SJ65/33	220	12	55
WS-110 I	Ф 20-110	SJ65/33	220	12	55
WS-160 I	Ф 50-160	SJ75/33	400	10	110
WS-250 I	Ф 90-250	SJ90/33	400	6	110
WS-450 I	Ф 160-450	SJ120/33	500	4	160
WS-630 I	Ф 400-630	SJ120/33	850	2	280
WS-800 II	Ф 500-800	SJ120/33	850	2	280
WS-630 I	Ф 315-630	SJ120/33	850	2	355
WS-800 I	Ф 500-800	SJ150/33	1100	1	400

38D Series High Efficient Production Line：

Production Line	Diameter Range（mm)	Extruder Type	Max. Capacity （kg/h）	Max. Haul Off Speed（m/min）	Extrusion Power（kw）
WS-63Ⅱ	Ф 20-63	WSD60/38	320	30	70
WS-110Ⅱ	Ф 20-110	WSD60/38	380	20	90
WS-160Ⅱ	Ф 40-160	WSD60/38	460	15	110
WS-250Ⅱ	Ф 50-250	WSD75/38	600	12	160
WS-450Ⅱ	Ф 110-450	WSD90/38	850	8	250
WS-630Ⅱ	Ф 250-630	WSD90/38	1050	4	280
WS-800Ⅱ	Ф 500-800	WSD120/38	1300	2	355
WS-1200Ⅱ	Ф 710-1200	WSD75/38 WSD90/38	1450	1	160/250
WS-1600Ⅱ	Ф 1000-1600	WSD90/38 WSD90/38	1900	0.6	280/280
