Product Description
Winsoar 20-1600mm HDPE Pipe Extrusion Line for Large Diameter Projects is a supporting PE pipe extrusion page for buyers comparing large diameter HDPE water, gas and irrigation pipe projects. It helps confirm the practical pipe diameter range, application, extrusion configuration and quotation information before choosing a complete HDPE pipe production solution.
This broad PE project page is useful when a buyer is planning a large diameter pipe factory or a project covering several diameter groups. It should support early-stage selection and then guide the buyer toward the most suitable core PE product page.
A wide-range HDPE project may require different line models for small, medium and large pipe sizes. Standard equipment includes single screw extruder, die head, vacuum calibration, cooling tanks, haul-off, cutter and stacker or coiler. Large-diameter sections need stronger traction, longer cooling and stable cutting.
For a range as wide as 20-1600mm, the final plan is usually split into practical diameter groups. Use the linked core PE pages to compare 16-63mm, 20-110mm, 75-250mm, 200-400mm and 315-800mm production needs.
For a practical quotation, prepare pipe diameter, wall thickness or SDR, raw material type, pipe application, output target, cutting or coiling requirement, workshop voltage and available factory space. These details help Winsoar match the extruder, die head, vacuum calibration, cooling, haul-off, cutter and downstream equipment correctly.
This older PE product page is maintained as a supporting long-tail page. For the main product range, visit the PE Pipe Production Line category.
Useful guides: machines included in a PE pipe production line, PE pipe production line process, PE pipe production line cost and HDPE pipe extrusion line selection guide. Video references: 16-63mm PE video solution, 20-110mm PE video solution, 75-250mm PE video solution, 200-400mm PE video solution, 315-800mm PE video solution.
Features
The optimum spiral structure-feeding throat highly improves the output of extruder;
Accurate temperature control system ensures materials melting performance;
Unique screw design achieves better plasticizing and high-quality products;
Precisely designed gearbox with a high torsion guarantees stable running;
"H" shape frame to decrease vibrating of extruder;
Advanced PLC operation system realizes synchronization and automation;
Adopt automatic water temperature & level control and special independent filters on both vacuum and cooling tanks;
Offer stable haul-off unit with 2-12 caterpillars;
Provide saw & chip-free cutting options;
Low energy consumption, excellent performance, and easy maintenance.
Key Components
Main Technical Parameter
33D Series Classical Production Line：
Production Line | Diameter Range（mm） | Extruder Type | Max. Capacity （kg/h） | Max. Haul Off Speed（m/min） | Extrusion Power（kw） |
WS-63 I | Ф 20-63 | SJ65/33 | 220 | 12 | 55 |
WS-110 I | Ф 20-110 | SJ65/33 | 220 | 12 | 55 |
WS-160 I | Ф 50-160 | SJ75/33 | 400 | 10 | 110 |
WS-250 I | Ф 90-250 | SJ90/33 | 400 | 6 | 110 |
WS-450 I | Ф 160-450 | SJ120/33 | 500 | 4 | 160 |
WS-630 I | Ф 400-630 | SJ120/33 | 850 | 2 | 280 |
WS-800 II | Ф 500-800 | SJ120/33 | 850 | 2 | 280 |
WS-630 I | Ф 315-630 | SJ120/33 | 850 | 2 | 355 |
WS-800 I | Ф 500-800 | SJ150/33 | 1100 | 1 | 400 |
38D Series High Efficient Production Line：
Production Line | Diameter Range（mm) | Extruder Type | Max. Capacity （kg/h） | Max. Haul Off Speed（m/min） | Extrusion Power（kw） |
WS-63Ⅱ | Ф 20-63 | WSD60/38 | 320 | 30 | 70 |
WS-110Ⅱ | Ф 20-110 | WSD60/38 | 380 | 20 | 90 |
WS-160Ⅱ | Ф 40-160 | WSD60/38 | 460 | 15 | 110 |
WS-250Ⅱ | Ф 50-250 | WSD75/38 | 600 | 12 | 160 |
WS-450Ⅱ | Ф 110-450 | WSD90/38 | 850 | 8 | 250 |
WS-630Ⅱ | Ф 250-630 | WSD90/38 | 1050 | 4 | 280 |
WS-800Ⅱ | Ф 500-800 | WSD120/38 | 1300 | 2 | 355 |
WS-1200Ⅱ | Ф 710-1200 | WSD75/38 WSD90/38 | 1450 | 1 | 160/250 |
WS-1600Ⅱ | Ф 1000-1600 | WSD90/38 WSD90/38 | 1900 | 0.6 | 280/280 |
